FC281 Fan Coil Thermostat

FC281-5DO: 3 Speed Fan or EC Fan, On/off valve or 0-10V valve
Communication: Wifi(Tuya), RS485
Color: Black/White color
Window contact/roomcard contact input port
External sensor
Sensor Type: Temperature humidity sensor
Power Supply: 220VAC+10% 50/60HZ
Set Temp. Range: 1~50°C
Control Precision: ±1°C
Shape Dimension: 86*86*14.5mm
Load Current: <3A
Power Box Dimension: 50*50*33mm
Viewing Dimension: 77*57mm
Net Weight: 300g

Inquiry

Overview
Inquiry
Related Products

Product Description

The fan coil room thermostat has been designed for individual control of temperature in commercial, industrial and residential

buildings. It is tailored for two-pipe fan coil with two-wire electric valves , three -wire electric valves ,PWM valve and floating point valve ,or four pipe fan coil with two-wire electric valves and PWM valve. With its flush mounted modern design the device

combines digital technology with a large LCD display and additional buttons, which enables the single room controller to be used intuitively.

Power supply	100~240VAC 50/60Hz
Load current	<3A
Temperature controlled accuracy	±1ºC
Ambient temp	0 ºC - 50.0ºC
Shape dimension (whd)	display board: 868614.3mm
Protection	IP20
Control Precision	±1ºC
Storage Temperature	-10~60ºC
Inputs	Passive Sensor
Outputs	Relays or 0-10v signal
Sensor Type	NTC10K
LCD	Touch Screen (77*66mm)
Enclosure Material	Fire proof ABS; Anti-reflective tempered glass
Installation Type	Flush mounted with standard EU box
